UF V (E3) 03/2019 Page 21/116
2.3 Main power switch
The main power switch is located on the bottom right side of the chamber.
In addition, a lockable protective flap covering the main power switch is optionally available. It can be un-
locked with a key and then removed.
(4)
(5a)
(5)
Standard chamber Chamber with optional lockable protective flap
Figure 9: Position of the main power switch and the lockable protective flap (option) on the right side of the
chamber
(4) Main power switch
(5) Lockable protective flap (option)
(5a) Key lock of the optional lockable protective flap
Off Onn
Figure 10: Main power switch (4) on the right side of the chamber
