UF V (E3) 03/2019 Page 30/116
4. Installation and connections
4.1 Operating instructions
Depending on the application and location of the chamber, the operator of the freezer must provide the
relevant information for safe operation of the chamber in a set of operating instructions.
Keep these operating instructions with the chamber at all times in a place where they are
clearly visible. They must be comprehensible and written in the language of the employees.
4.2 Spacers for rear wall distance
Please fix both spacers with the supplied screws at the chamber rear. This serves to ensure the pre-
scribed minimum distance to the rear wall of 100 mm / 3.94 in.
Figure 15: Spacer for rear wall distance Figure 16: Rear UF V 700 with mounted spacers
