24 | Installation
BioTek Instruments, Inc.
Required Materials
Hex wrench (which should be stored in the small plastic storage pouch
attached to the back of the instrument)
Affix the shipping brackets
1. Turn off the MicroFlo.
2. To install the plate carrier shipping bracket, slide the plate carrier to the left.
Line up the U in the bracket’s short branch with the back rail and use the
hex wrench to screw the long branch to the plate carrier’s rail. (See the
picture on page 12).
Removing the plate carrier may make it easier to install the plate carrier shipping
bracket. Restore the carrier before installing the dispense arm bracket.
3. To install the dispense arm shipping bracket, put the hole in the bracket’s
short arm over the back rail so that the black foam patch on the wider
branch protects the plate carrier from being scratched. Lower the dispense
arm to align the screw holes and use the hex wrench to secure it. The
bracket will hold the dispense arm just above the plate carrier.
4. Close the Pump Cover and secure it in place with the rubber band.
