Define the Cassette
  Dispenser Action Menu> SETUP> CASS
It is important to correctly identify the cassette type for accurate dispensing. The current
cassette setting is shown in the main menu.
(384) CASS(10) VOL:0010µL
Prime Purge uPlate 
   
CASS(#) in the top line of the LED displays the current Cassette setting. Likewise, the
cassette is prominently labeled. Make sure the MicroFlo’s setting matches the currently
used cassette.
The MicroFlo displays a warning message when an out-of-range volume is defined for the
current cassette. For example, if you request a 150 µL dispense with a 1 µL cassette, a
message will require you to confirm your intention or cancel the run.
To define the cassette type:
1. At the MicroFlo’s main menu, select  twice to get to the Dispenser Action
Menu.
2. Select SETUP.
3. Select CASS.
4. Select the 1 µL, 5 µL, or 10 µL cassette. 0.
This action returns you to the Setup Options. The cassette type is changed to
your selection. Confirm this at the main menu: press
Main Menu twice.
Removing the Tubing Cassette
 Review the Tubing Cassette Diagram on page 14.
1. Lift the Tube Organizer out of the fluid vessel.
2. Move the Pump Cover away from the pump to its off position.
3. Release the stainless steel plate holding the Tube Tensioner: release the catch on
the top front of the pump that holds it in place. It will hang loosely.
4. Lift the Center Holder out of its slot on the right side of the pump.
5. Hold the Center Holder in one hand while you slide the Tip Holder out of the
dispense arm.
