Bitmos sat801+ - 4.4 Pictograms on the Unit; 4.5 USB-Interface

sat801+ Pulse Oximeter
Assembly
18
4.4 Pictograms on the Unit
Symbol Bedeutung
Consult instructions for use!
On / Off button
Menu / OK button
Navigation button right / up
Navigation button left / down
Alarm tone mute
IP 22
Ingress Protection Rating
Manufacturer
Ambient pressure range storage condition
Humidity storage range condition
Temperature range storage condition
Model number
Serial number
Defi-proof applied part type BF
4.5 USB-Interface
ATTENTION!
To connect to the interface use only original manufactured parts. Otherwise the unit
could be damaged.
