The Blustream Multicast Receiver has an in-built video scaler which can both up-scale and downscale video signals
allowing the best picture quality possible at each display.
Configuration of Multicast Scaler settings can be achieved in several ways:-
1 During the manual configuration of the Multicast Receiver
2 Using the Blustream Multicast PC configuration soware
3 Using the Multicast Web GUI interface
4 Using RS-232 commands via the Blustream CM100
When configuring the Scaling during manual setup or using RS-232 commands the following table indicates Scaler
settings.
Scaler Output Control
SCALER MULTICAST RECEIVER SCALER SETTINGS
00 Passthrough
01 HDMI 1080p@50Hz
02 HDMI 1080p@60Hz
03 HDMI 720P@60Hz
04 HDMI 720P@50Hz
05 HDMI 1280 x 1024@60Hz
06 HDMI 1024 x 768@60Hz
07 HDMI 1360 x 768@60Hz
08 HDMI 1440 x 900@60Hz
09 HDMI 1680 x 1050@60Hz
10 HDMI 4K2K@30Hz
11 HDMI 4K2K@24Hz
