BluStream IP100UHD-TX - Specifications; Package Contents; Maintenance

MULTICAST USER MANUAL
54
www.blustream.co.uk
Specifications
Package Contents
IP100UHD-TX
• Video input: 1x HDMI type A, female
• Video output: 1x LAN RJ45 connector
• Audio input:1x 3.5mm L/R analogue audio
• Ethernet port: 1x LAN RJ45 connector
• RS-232 serial port: 1x 3-pin phoenix connector
• IR input: 1x 3.5mm stereo jack
• IR output: 1x 3.5mm mono jack
• Mounting kit included
• Dimensions (W x D x H ): 190mm x 108mm x 25mm
• Shipping weight (Kit): 0.75kg
• Operating temperature: 32°F to 104°F (0°C to 40°C)
• Storage temperature: -4°F to 140°F (-20°C to 60°C)
IP100UHD-TX
• 1x IP100UHD-TX
• 1x Mounting kit for IP100UHD-TX
• 1x IR emitter
• 1x IR receiver
• 1x ID sticker
Maintenance
IP100UHD-RX
• 1x IP100UHD-RX
• 1x Mounting kit for IP100UHD-RX
• 1x IR emitter
• 1x IR receiver
• 1x ID sticker
IP100UHD-RX
• Video input: 1x LAN RJ45 connector,
• Video output: 1x HDMI type A, female
• Audio output: 2x RCA L/R analogue audio
• Ethernet port: 1x LAN RJ45 connector (video extension)
• RS-232 serial port: 1x 3-pin phoenix connector
• IR input: 1x 3.5mm stereo jack
• IR output: 1x 3.5mm mono jack
• Mounting kit included
• Dimensions (W x D x H ): 190mm x 108mm x 25mm
• Shipping weight (Kit): 0.75kg
• Operating temperature: 32°F to 104°F (0°C to 40°C)
• Storage temperature: -4°F to 140°F (-20°C to 60°C)
Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
CM100
• Ethernet port: 2x LAN RJ45 connector
• RS-232 serial port: 1x 3-pin phoenix connector
• IR input: 1x 3.5mm stereo jack
• Dimensions (W x D x H ): 89mm x 85mm x 23mm
• Shipping weight (Kit): 0.4kg
• Operating temperature: 32°F to 104°F (0°C to 40°C)
• Storage temperature: -4°F to 140°F (-20°C to 60°C)
CM100
• 1x CM100
• 1x IRCAB IR Control cable
• 1x Serial 3-pin phoenix connector
