8 | First Steps
16/144 Manual_C_80 Bosch Motorsport
1. Start the RaceCon software.
2. In the ‘File’ menu select ‘New project’ to create a new project.
3. In the Toolbox select the C 80 and drag it into the Main Area. A pop up window to
specify the C 80 program archive appears.

Bosch C 80 Specifications

General

Resolution	16 bit
Interfaces	USB
Measurement Range	±10V
Accuracy	±0.1 % FS
Channels	8 universal analog inputs (±10 V, ±20 mA, Pt100, Pt1000, Thermocouples type K, S, J, T, N, R, B, E), 4 digital inputs (trigger, counter, frequency), 2 digital outputs (24 V / 500 mA)
