12 | Analog and Frequency Inputs
74/144 Manual_C_80 Bosch Motorsport
Drag + Drop
A ‘Calculated Speed Wizard’ opens.
Choose device
Choose input source
(internal/external)
Choose driven axle
Choose individual wheel
speed channels
Set limit for speed
difference for calculation
4. Click ‘Finish’ when done.
The speed calculation is inserted into the C 80 Project Tree.
Speed calculation
in DDU Project
Tree
Measurement
channels
calculated speed
and calculated
distance
Configuration
window
