Online Measurement and Calibration | 13
Bosch Motorsport Manual_C_80 79/144
2. To create the sheets, right-click on C 80 and select ‘Create measurement views…’ from
the C 80 context menu.
Click to create
measurement sheets
The automatically created sheet is inserted in the Project Tree under ‘Measurement
Container’ and ‘Device Channels’. If the C 80 is connected to RaceCon and the status
is green, live values of the channels are shown.
13.1.2 Using the measurement sheets
1. When RaceCon is online, press the ‘F11’ key to switch from ‘Design Mode’ into ‘Race
Mode’. The measurement sheet is extended to full screen. The button for offset calib-
ration is active.
2. Switch between different sheets using the tabs at the bottom of the window.
3. Press the ‘Esc’ key to return to ‘Design Mode’.
