Description Symbol Unit
HCS03.1E-
W0070-_-05
HCS03.1E-
W0100-_-05
HCS03.1E-
W0150-_-05
HCS03.1E-
W0210-_-05
maximum output current at
I
out_base_1
; f
s
= 16 kHz; t = 0,4 s;
T = 4 s; K = 2,5
5)
I
out_peak1_16
A 31,31 42,79 65,24 92,58
base load current at I
out_peak_1
;
f
s
= 16 kHz; t = 0,4 s; T = 4 s; K = 2,5
I
out_base1_16
A 12,52 17,12 26,10 37,03
maximum output current at
I
out_base_3
; f
s
= 2 kHz; t = 2 s; T = 20 s;
K = 2,0
6)
I
out_peak3_2
A -
base load current at I
out_peak_3
;
f
s
= 2 kHz; t = 2 s; T = 20 s; K = 2,0
I
out_base3_2
A -
maximum output current at
I
out_base_3
; f
s
= 4 kHz; t = 2 s; T = 20 s;
K = 2,0
7)
I
out_peak3_4
A 66,15 91,81 135,86 210,00
base load current at I
out_peak_3
;
f
s
= 4 kHz; t = 2 s; T = 20 s; K = 2,0
I
out_base3_4
A 33,07 45,91 67,93 105,00
maximum output current at
I
out_base_3
; f
s
= 8 kHz; t = 2 s; T = 20 s;
K = 2,0
8)
I
out_peak3_8
A 47,56 63,92 95,46 148,43
base load current at I
out_peak_3
;
f
s
= 8 kHz; t = 2 s; T = 20 s; K = 2,0
I
out_base3_8
A 23,78 31,96 47,73 74,22
maximum output current at
I
out_base_3
; f
s
= 12 kHz; t = 2 s;
T = 20 s; K = 2,0
9)
I
out_peak3_12
A 34,94 46,52 70,06 106,87
base load current at I
out_peak_3
;
f
s
= 12 kHz; t = 2 s; T = 20 s; K = 2,0
I
out_base3_12
A 17,47 23,26 35,03 53,44
maximum output current at
I
out_base_3
; f
s
= 16 kHz; t = 2 s;
T = 20 s; K = 2,0
10)
I
out_peak3_16
A 26,33 34,78 53,13 80,58
base load current at I
out_peak_3
;
f
s
= 16 kHz; t = 2 s; T = 20 s; K = 2,0
I
out_base3_16
A 13,17 17,39 26,57 40,29
base load current at I
out_peak_4
;
f
s
= 2 kHz; t = 60 s; T = 5 min; K = 1,5
I
out_base4_2
A -
maximum output current at
I
out_base_4
; f
s
= 2 kHz; t = 60 s;
T = 5 min; K = 1,5
11)
I
out_peak4_2
A -
maximum output current at
I
out_base_4
; f
s
= 4 kHz; t = 60 s;
T = 5 min; K = 1,5
12)
I
out_peak4_4
A 47,66 75,04 108,03 162,72
base load current at I
out_peak_4
;
f
s
= 4 kHz; t = 60 s; T = 5 min; K = 1,5
I
out_base4_4
A 31,77 50,02 72,02 108,48
