12 Description of the devices
12.1 Plates
12.1.1 Positions of the plates
1 Warning labels
2 Type plate
3 Additional plate
Tab. 12-1: Positions of the plates
12.1.2 Warning labels
Tab. 12-2: Warning labels at the device
IndraDrive X Drive Controllers Power Sections XCS1, XMD1,
XMQ1
