5 Spare parts, accessories and wear parts
5.1 XAS2, shield connection
5.1.1 Type code
XAS2
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: X A S 2 - 0 0 1 - 0 0 1 - N N
① ② ③ ④
① Product:
XAS2 = IndraDrive X accessories, shield connection
② Device assignment:
001 = XMD1-W5454
001 = XMD1-W7070
002 = XCS1-W0100
002 = XCS1-W0120
003 = XMS1-W0100
003 = XMS1-W0120
004 = XCS1-W0210
004 = XCS1-W0250
004 = XCS1-W0280
③ Cable outlet:
001 = Downwards
002 = Backwards
④ Other design:
NN = None
Tab. 5-1: XAS2, type code
