Multiple-line design of the control cabinet
Arrangement of the devices, air guides/drip protections, fans
Pay particular attention to the maximum allowed air intake
temperature of devices when they are arranged in multiple lines in
the control cabinet.
If possible, place devices with a high degree of power dissipation
(e.g., supply units with braking resistors, DC bus resistor units)
● in the top line and
● near the outlet air aperture to the cooling unit
Mount air guides between the lines to
● protect the devices in the upper lines against the warm outlet
air of the devices beneath and
● protect the devices beneath against penetration of liquids
(e.g. dripping condensation water or leaking cooling liquid)
Additional fans convey the outlet air to the cooling unit and
cooling air to the upper lines.
At the installed control cabinet, check the air intake temperature
of all devices.
IndraDrive X Drive Controllers Power Sections XCS1, XMD1,
XMQ1
47/123
Mounting, dismounting and electrical installation
R911392532_Edition 01 Bosch Rexroth AG
