XD03, motor connection
Important notes
Lethal electric shock by live parts with more
than 50 V!
Only operate the device
● with the connectors plugged on (even if no lines have been connected
to the connectors) and
● with the equipment grounding conductor connected!
Risk of damage to the device!
Provide strain relief for the terminal connectors of the device in the control
cabinet.
Notes on installation
The specified connection cross sections are the cross sections that can be
connected. Dimension the required cross section of the connection lines
according to the occurring current load.
● Provide for optimum shield contact of the motor power cable.
● For the connection between drive controller and motor, use
our ready-made motor power cables, where possible.
IndraDrive X Drive Controllers Power Sections XCS1, XMD1,
XMQ1
73/123
Mounting, dismounting and electrical installation
R911392532_Edition 01 Bosch Rexroth AG
