9 Interfaces
9.1 Positions of the connection points
9.1.1 XCS1
XCS1-W0100
XCS1-W0120
XD02: DC bus
XG21: Multi-encoder
XG31: Digital inputs/outputs, analog inputs
XG41: Safety technology
XF21, XF22: Communication
Tab. 9-1: XCS1, front
