Motor connection: Overview
There are three different types of motor connections:
● Screw connection at device ( ).
● Screw connection at connector ( ).
● Spring terminal at connector (
).
The table below gives an overview of motor connections.
Component
PE + XD03
XD03
XZ03
XCS1 1×
W01xx: 35 mm
2
- -
XMD1 - 2×
W5454, W7070: 10 mm
2
2×
W0606…2323: 10 mm
2
XMQ1-WQ001 - 2×
W36, W54: 10 mm
2
2×
W10, W20: 10 mm
2
PE + XD03 Screw connection at device
XD03 Screw connection at connector
XZ03 Spring terminal at connector
Tab. 10-5: Motor connection: Overview
