Description Symbol Unit Value
Vibration sine: amplitude (peak-peak) at
10 … 57 Hz
mm 0.15
Vibration sine: acceleration at 57 … 150 Hz g 1
Overvoltage category III (according to IEC 60664-1)
1) Reduced performance data for drive controllers: allowed DC
bus continuous power, braking resistor continuous power, con‐
tinuous current; additionally for converters: allowed mains volt‐
age
Tab. 6-1: Ambient and operating conditions
6.1 Transporting the components
Ambient and operating conditions - transport
Description Symbol Unit Value
Temperature range T
a_tran
°C -25 … +70
Relative humidity % 5 … 95
Absolute humidity
g/m
3
1 … 60
Climatic category (IEC721) 2K3
Moisture condensation Not allowed
Icing Not allowed
Tab. 6-2: Ambient and operating conditions - transport
6.2 Storing the components
Risk of damage to components from long-
term storage!
Some components contain electrolytic capacitors which may deteriorate
during storage.
When storing the following components for a longer period of time, run them
once a year for at least 1 hour:
● Converters and supply units: Operated with mains voltage U
LN
● Inverters and DC bus capacitor units: Operated with DC bus voltage
U
DC
Ambient and operating conditions - storage
Description Symbol Unit Value
Temperature range T
a_store
°C -25 … +55
Relative humidity % 5 … 95
Absolute humidity
g/m
3
1 … 29
Climatic category (IEC721) 1K3
IndraDrive X Drive Controllers Power Sections XCS1, XMD1,
XMQ1
29/123
Ambient conditions
R911392532_Edition 01 Bosch Rexroth AG
