Place these warning labels clearly visibly at the component or in
the immediate vicinity of the component, if the warning labels
existing at the component are hidden by neighboring
components.
12.2 Diagnostic display
12.2.1 PF01 LED (Device State)
Fig. 12-1: PF01 LED
IndraDrive X Drive Controllers Power Sections XCS1, XMD1,
XMQ1
99/123
Description of the devices
R911392532_Edition 01 Bosch Rexroth AG
