Tab. 1-3: Documentations – firmware
1.4.3 Motors
Title Type of documentation
Document typecode
1)
DOK-MOTOR*-…
Material number
R911…
MAD / MAF
Asynchronous Motors MAD / MAF
Project Planning Manual MAD/MAF****-PRxx-EN-P 295781
MBS-H
Synchronous Kit Spindle Motors
Project Planning Manual MBS-H******-PRxx-EN-P 297895
MLF
Synchronous Linear Motors
Project Planning Manual MLF********-PRxx-EN-P 293635
MCL
Ironless Linear Motors MCL
Project Planning Manual MCL********-PRxx-EN-P 330592
MKE Synchronous Motors
Synchronous Servo Motors
for Potentially Explosive Areas
acc. to ATEX and UL / CSA
Project Planning Manual MKE*GEN2***-PRxx-EN-P 297663
MSK
Synchronous Servo Motors
Project Planning Manual MSK********-PRxx-EN-P 296289
MSK
Synchronous Servo Motors
for Potentially Explosive Areas
Project Planning Manual MSK*EXGIIK3-PRxx-EN-P 312709
MSM
Synchronous Servo Motors
Data Sheet MSM********-DAxx-EN-P 329338
MS2E
Synchronous Servo Motors
acc. to ATEX Directive 2014/34/EU
Project Planning Manual MS2E*******-PR01-EN-P 394140
