14 en | Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts VG4 Modular Camera Series
F.01U.162.025 | 6.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
The following figures depict the parts (some optional) for a pendant arm wall, corner, or mast
mount.
Corner Plate
(optional)
Mast Plate
(optional)
Mounting Plate
(optional)
Trim Skirt
(optional)
Power Supply
Pendant Arm
Pendant Housing
Environmental Shield (optional)
Pressurized Environmental Housing (optional)
Heater Module (optional)
COMMS
Module
CPU Module
Camera
Module
Dome Bubble
Bubble Support Ring for Pressurized Environmental Housing
(optional)
