VG4 Modular Camera Series Installing Roof Parapet and Pipe Mounts | en 49
Bosch Security Systems, Inc. Installation Manual F.01U.162.025 | 6.0 | 2010.03
3.4.1 Wiring the Power Supply Box
1. Route the high voltage 115/230 VAC lines through the conduit fitting on the left side of
the box.
2. Cut and trim the high voltage 115/230 VAC power and ground wires with sufficient slack
to reach their connector terminal in the box, but not so long as to be pinched by or to
obstruct closing the Cover Door. See Section 3.1.1 Parts List, page 42, for connector
location.
3. Attach the supplied 3-pin Power Plug to the incoming high voltage power wires in the
box. See connector P101 in Table 3.1, Page 52.
4. Route the low power 24 VAC wires from the right side of the Power Supply Box out to
where the AutoDome will be mounted. Attach the supplied 5-pin 24 VAC Dome plug to
the wire ends inside the box. See connector P107 in Table 3.1, Page 52.
5. If you are using UTP for video or Ethernet, route the UTP cable out to where the
AutoDome will be mounted. See Section 5 Cable and Wire Standards, page 85 for fiber
optic specifications.
3.4.2 Wiring the Fiber Optic Model
1. If installing a Fiber Optic model, bring the fiber optic cable into the right side of the
power supply box.
2. Route a video coax cable from the Power Supply Box to the Pipe Interface Board. Then
attach a BNC connector to the cable end inside the Power Supply Box. See
Section 5 Cable and Wire Standards, page 85 for fiber optic specifications.
NOTICE! The Power Supply Box with transformer comes with a barrier that separates the high
voltage side on the left from the low voltage 24 VAC side on the right.
NOTICE! All video, control, and alarm wires either pass through the Power Supply Box or by-
pass it and connect directly to the Pipe Interface Board.
NOTICE! You will need a barrel connector (not supplied) to connect the BNC connector from
the Pipe Interface Board coax cable to the Fiber Optic Module BNC connector.
