VG4 Modular Camera Series Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts | en 13
Bosch Security Systems, Inc. Installation Manual F.01U.162.025 | 6.0 | 2010.03
2 Installing the Pendant Arm Wall, Corner, and Mast
(Pole) Mounts
2.1 Unpacking
This equipment should be unpacked and handled with care. If an item appears to have been
damaged in shipment, notify the shipper immediately.
Verify that all the parts listed in the Parts List below are included. If any items are missing,
notify your Bosch Security Systems Sales or Customer Service Representative. See
Section 1.5 Customer Support and Service, page 12 for contact information.
The original packing carton is the safest container in which to transport the unit and must be
used if returning the unit for service. Save it for possible future use.
2.1.1 Parts List
The following table lists the parts included with the Pendant Arm Wall, Corner, or Mast mount
packages.
Mount Kit Options Part Numbers
Pendant Arm (Only) F01U010586
Pendant Arm with Mounting Plate
(24 V VG4 models only, no power supply box)
VG4-A-ARMPLATE
Pendant Housing (with COMMS and CPU modules installed):
– Analog VG4 AutoDome
– IP-enabled AutoDome
VG4-XXX-O or -S
VG4-XXX-E
Optional Housing Modules
– Environmental Shield
– Pressurized Environmental Housing
VG4-MHSG-EX
VG4-MHSG-NX
Pendant Arm with one of the following Power Supply Boxes:
– Power Box without transformer (24 VAC) VG4-A-PA0
– Power Box with 120 VAC transformer
or with 230 VAC transformer
VG4-A-PA1
VG4-A-PA2
– Power Box without transformer with Fiber Optic Module (24 VAC) VG4-A-PA0F
– Power Box with 120 VAC transformer and Fiber Optic Module
or with 230 VAC transformer and Fiber Optic Module
VG4-A-PA1F
VG4-A-PA2F
Trim Skirt Power Supply Box F01U005225
Corner Mount Kit
– Corner Mount Plate VG4-A-9542
Mast (Pole) Mount Kit
– Mast Mount Plate VG4-A-9541
Bubble
– Clear Bubble with white trim ring, or
– Tinted Bubble with white trim ring
– Optional white bubble support ring for Pressurized Environmental
Housing
VG4-SBUB-PCL
VG4-SBUB-PTI
