42 en | Installing Roof Parapet and Pipe Mounts VG4 Modular Camera Series
F.01U.162.025 | 6.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
3 Installing Roof Parapet and Pipe Mounts
3.1 Unpacking
This equipment should be unpacked and handled with care. If an item appears to have been
damaged in shipment, notify the shipper immediately.
Verify that all the parts listed in the product's Parts List below are included. If any items are
missing, notify your Bosch Security Systems Sales or Customer Service Representative. See
See Section 1.5 for Customer Support and Service contact information.
The original packing carton is the safest container in which to transport the unit and must be
used if returning the unit for service. Save it for possible future use.
3.1.1 Parts List
The following table lists the parts included with the Roof Parapet and Pipe mount packages:
Mount Kit Options Part Numbers
Parapet (Roof) Mount with one of the following Power Supply Boxes: VG4-A-9230
– Power Supply Box with 120 VAC transformer
or 230 VAC transformer
VG4-A-PSU1
VG4-A-PSU2
– Power Supply Box with Fiber Optic Module and 120 VAC transformer,
or 230 VAC transformer
VG4-A-PSU1F
VG4-A-PSU2F
– Power Supply Box without transformer (24 VAC) and with Fiber Optic
Module
VG4-A-PSU0F
Optional Flat Roof Mount Adapter for VG4-A-9230 Mount (not included) LTC 9230/01
Pipe Mount with one of the following Power Supply Boxes: VG4-A-9543
– Power Supply Box with transformer 120 VAC
or 230 VAC transformer
VG4-A-PSU1
VG4-A-PSU2
– Power Supply Box with Fiber Optic Module and 120 VAC transformer
or 230 VAC transformer
VG4-A-PSU1F
VG4-A-PSU2F
– Power Supply Box without transformer (24 VAC) and with Fiber Optic
Module
VG4-A-PSU0F
Bubble
– Clear Bubble with white trim ring, or
– Tinted Bubble with white trim ring
– Optional white bubble support ring for Pressurized Environmental
Housing
VG4-SBUB-PCL
VG4-SBUB-PTI
