Bosch VG4 Series Installation Manual

VG4 Modular Camera Series Installing the In-Ceiling Mount | en 77
Bosch Security Systems, Inc. Installation Manual F.01U.162.025 | 6.0 | 2010.03
5. Tighten the four (4) securing screws to the Bracket Assembly.
Figure 4.4 Tighten Bracket Securing Screw
6. Secure the Bracket Assembly to an overhead securing point with a safety wire.
Figure 4.5 Secure Bracket Assembly

Bosch VG4 Series Specifications

General

Weatherproof Rating	IP66
Pan Range	360° continuous
Communication	RS-485
Lens Type	Varifocal
Day/Night	Yes
Power	12V DC
