Brainchild PR20 User Manual

Page 122 of 479
5-14 Display Unit for IN1 & IN2
*B14: Display Symbol and Description for DP1 &DP2
Parameter Value
Display Symbol
Description
0
NO-DP
No Decimal Digit
1
1-DP
One Decimal Digit
2
2-DP
Two Decimal Digits
3
3-DP
Three Decimal Digits
5-15 Decimal Digit for DP1 & DP2
*B15: Display Symbol and Description for IN2
Parameter Value
Display Symbol
Description
0
NONE
IN2 No Function
1
CT
Current Transformer Input
2
4-20
4-20mA Linear Current Input
3
0-20
0-20mA Linear Current Input
4
0-1V
0-1V Linear Voltage Input
5
0-5V
0-5V Linear Voltage Input
6
1-5V
1-5V Linear Voltage Input
7
0-10
0-10V Linear Voltage Input
5-16 IN2 Input
*B16: Display Symbol and Description for EIFN
Parameter Value
Display Symbol
Description
0
NONE
Event Input No Function
1
SP2
SP2 Activated to replace SP1
2
PID2
PB2,TI2,TD2 Activated to replace PB1,TI1,TD1
3
SP.P2
SP2,PB2,TI2,TD2 Activated to replace SP1,PB1,TI1,TD1
4
RS.A1
Reset Alarm 1 Output
5
RS.A2
Reset Alarm2 Output
6
R.A1.2
Reset Alarm1 & Alarm2 Output
7
D.O1
Disable Output1
8
D.O2
Disable Output2
9
D.O1.2
Disable Output1 &Output 2
10
LOCK
Lock All Parameters
5-17 EIFN Function
*B17: Display Symbol and Description for OUT1
Parameter Value
Display Symbol
Description
0
REVR
Reverse(Heating)Control Action
1
DIRT
Direct(Cooling)Control Action
5-18 Out1 Action
*B18: Display Symbol and Description for O1TY & O2TY
Parameter Value
Display Symbol
Description
0
RELY
Relay Output
1
SSRD
Solid State Relay Drive Output
2
SSR
Solid State Relay Output
3
4-20
4-20mA Current Module
4
0-20
0-20mA Current Module
5
0-1V
0-1V Voltage Module
6
0-5V
0-5V Voltage Module
7
1-5V
1-5V Voltage Module
8
0-10
0-10V Voltage Module
5-19 Out1 & Out2 Type
