Various options are available to enter into configuration page menus.
Option-1: Select the required menu by using up & down directional keys, then press “Enter” key
Option-2: Select the required menu directly with a touch, then press “Enter” key
Option-3: Select the required menu by pressing the menu two times quickly, it is same as a double click
from a mouse
There are four soft key are available to save, load, to load the default settings and move to home
screen. They are below.
Save
Save configuration from the recorder to a USB disk or an SD Card.
Load
Load configuration from a USB Disk or SD Card to the recorder.
Default
Load the factory default setting to the configuration menu parameters.
Home
Returns the display back to the home page.
5.1 Channel
This section will explains the configuration of different types of channels. They are as below.
1. Analog Input (AI)
2. Digital Input (DI)
3. Math
4. Analog Output (AO)
5. Digital Output (DO)
6. External device channels.
5.1.1 Analog Input
After entering the Configuration menu, in Channel”, select “AI, then Press the “Enter” key to
get into Analog Input Channel configuration menu. It displays the Analog input AI1 as the first analog input
channel configuration page. Press directional navigation keys at the bottom to select
other channels. Press directional keys on the right hand side to select the column.
After completing Configuration, press soft key, then press soft key to return to
main display. All configurations will be saved automatically.
