Brainchild PR20 User Manual

Page 428 of 479
Modbus Address
Notation
Register Name
Access
1941
C8_SPMD
Set point mode selection6
0 : SP1.2
1 : MIN.R
2 : HR.R
3 : PV1
4 : PV2
5 : PUMP
R
1943
C8_EIFN
Event input function7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
1945
Reserve
Reserve
R
1947
C8_SP1
Set point 1
R
1949
C8_SP2
Set point 2
R
1951
C8_Profile
Profile number
R
1953
C8_Segment
Segment number
R
1955
C8_Cycle
Cycle remaining for the current loop
R
1957
C8_Run
Profile running
R
1959
C8_Hold
Profile held
R
1961
C8_Up
Running ramp up segment
R
1963
C8_Down
Running ramp down segment
R
1965
C8_Unit
Current input unit
R
1967
C8_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
8.1.1.7 System Information (Integer Type)
Modbus Address
Register Name
Access
901
Percentage free of internal memory
R
902
Percentage free of external memory
R
8.1.1.8 System Information (Float Type)
Modbus Address
Register Name
Access
2901
Percentage free of internal memory
R
2903
Percentage free of external memory
R
