5.3 Jobs
There are various types of jobs available in the recorder to activate by an event. The available
jobs are listed as below.
5.3.1 No Action
Do nothing
5.3.2 Send Email
Send Email directly from Recorder
5.3.3 Pause
Stop logging data.
5.3.4 Start
Start logging data.
5.3.5 Sound Buzzer
Sound the buzzer. It stops once any key is pressed.
5.3.6 Dump Data
Dump the historical data from internal memory to external memory such as SD Card or USB
Disk. The user can select the data to be dumped to external memory.
5.3.7 DO Latch On
Set digital output / relay on, and then select Target, let’s say from one of DO 1 to DO 6. The
relay is latched when it is activated.
5.3.8 DO Latch Off
Set digital output / relay off, and then select Target, let’s say from one of DO 1 to DO 6. The
relay is un-latched when it is activated.
5.3.9 DO Process
Set digital output / relay on for process high or low, and then select the target, let’s say from 1 of
DO 1 to DO 6. The relay is not going to be latched when it is activated.
