1.8.3 PR30 Ordering code
PR3006 (6 Analog Inputs) -
PR3012 (12 Analog Inputs)
PR3018 (18 Analog Inputs)
PR3024 (24 Analog Inputs)
PR3030 (30 Analog Inputs)
PR3036 (36 Analog Inputs)
PR3042 (42 Analog Inputs)
PR3030 (48 Analog Inputs)
Relay
0: none
1: 6 Relays
2: 12 Relays
3: 18 Relays
4: 24 Relays
Digital Inputs
0: none
1: 6 Channels
2: 12 Channels
3: 18 Channels
Analog Outputs
0: none
1: 6 Channels
2: 12 Channels
Power
A: 90-250 VAC, 50/60 Hz
D: 11-36 VDC (UL Certification Not available)
Communication
0: standard Ethernet interface
1: Ethernet + RS-232
2: Ethernet + RS-422/485
Firmware
0: Standard Version with Mathematic Functions
1: Plus Version 1 with external channels, batch & FDA 21 CFR part 11
2: Plus Version 2 with editable custom display and Panel Studio software
3: Plus Version 3- includes Plus Version 1+2 above
PC Software
1: Free Basic Software of Historical Viewer and Configuration
2: Extensive software Data Acquisition Studio
(Real Time Viewer + Historical Viewer + Configuration)
Mounting types, Power Cord & Switch
0: panel mount, no power cord, no power switch
1: panel mount, no power cord, power switch
2: portable, UL & CSA power cord, power switch
3: portable, VDE power cord, power switch
4: portable, SAA power cord, power switch
5: portable, BS power cord, power switch
6: portable, no power cord, power switch
7: Panel mount, UL & CSA power cord, power switch
8: Panel mount, VDE power cord, power switch
9: Panel mount, SAA power cord, power switch
A: Panel mount, BS power cord, power switch
Special options
00: none
S1: 16G SD card
S2: 32G SD card
