5.3.25 Print Snapshot
Prints the snapshot of the screen.
5.3.26 Output Historical Data
This will generate a historical data output in CSV format in external storage. It will also contains
event reports.
5.3.27 Copy Value and Paste Value
This is mainly used for retransmission of Analog inputs using external (communication) Analog
output channels. Since we have limitation of Analog outputs on the Recorder. This external channels can be
used by using the copy value and paste value. This can be used by using event or timer when job 1 is copy
value, job2 will be paste value.
5.3.28 Select Controller
Select the PID Process controller card
5.3.29 Run Profile
Select the profile to run.
5.4 Display
This will allow the user to configure the real time display pages on the recorder. The maximum
no of display pages and pens per display page will vary depends on the recorder model no.
After entering the Configuration menu, select “Display” then Press the “Enter” key to get into
Display configuration menu. It displays the Display page Page1 as the first display page configuration page.
Press directional navigation keys at the bottom to select other pages. Press directional
keys on the right hand side to select the menu column. After completing
Configuration, press soft key, then press soft key to return to main display. All
configurations will be saved automatically.
