Standard one slot at Front
Standard one USB slot in front and one USB slot in the rear
Optional DI card support pulse Input up to 100Hz
Available by Standard version
External Channel,
Batch, Custom Display,
FDA 21 CFR Part 11
Available by plus versions
Convenient for local users by offering languages in Brazil Portuguese, Chinese
(Simplified, Traditional), Czech, Danish, Dutch, English, French, German, Greek,
Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Thai,
Turkish. Other Languages negotiable.
Available by Standard version
Standard Ethernet Port. Modbus TCP/IP (Server by default, Client available with
plus 1 version)
Optional Rs232 or Optional RS422/485. Modbus RTU (Slave by default, Master
available with plus 1 version)
Standard: Historical Viewer + Configuration
Optional: Extensive Software Data Acquisition Studio for real time monitoring
1.9.2 Analog Input Specifications (AI203 & AI206)
Channels: AI203 ~ 3 channels, AI206 ~ 6 channels
Resolution: 24 bits
Sampling Rate: 10 times/ second (100milliseconds)
Maximum Rating:
❖ RTD input ±20V
❖ Thermocouple and Voltage input ± 50V
❖ mA input ±10V
Temperature Effect:
❖ ±0.1uV ±15PPM of reading for all inputs except mA
❖ ±30PPM of reading for mA input
Sensor Lead Resistance Effect:
❖ Thermocouple: 0.32PPM of reading/Ω
❖ 3-wire RTD: 2.6˚C/Ω of resistance difference of two leads (Based on °C
measurement temperature for PT100)
❖ 2-wire RTD: 2.6˚C/Ω of resistance sum of two leads (Based on °C measurement
temperature for PT100)
Burn-out Current: 10uA
Common Mode Rejection Ratio (CMRR): 120dB
Normal Mode Rejection Ratio (NMRR): 55dB
Isolation Breakdown Voltage between channels: 1500VAC min.
Sensor Break Detection:
❖ Sensor opened for TC, RTD and mV inputs
❖ Below 1 mA for 4-20mA input
❖ Below 0.25V for 1-5V inputs
❖ Not available for other inputs
Sensor Break Responding Time:
❖ Within 1 seconds for TC, RTD and mV inputs
❖ 0.1 second for 4-20 mA and 1-5V inputs
