1 - 4
Outline of Mechanism Positions of electronic components
S2 (CS8000 Series)
S3 (CS8100 Series)
ASSY, POWER PCB S:ZSBA125I
Power switch/Inlet assy
PCB ASSY:OPERATION S2
ASSY:SSVR PCB
LED Lamp SR assy
PCB ASSY:OPERATION S2
ASSY:SSVR PCB
ASSY, POWER PCB S:ZSBA125I
Power switch/Inlet assy
SINGLE LIGHT GUIDE ASSY S3
LED Lamp SR assy
