Brother CS8000 Series - Does not operate when the foot controller is used.

5 - 12
Failure Investigation for Electronic Parts Does not operate when the foot controller is used.
Does not operate when the foot controller is
pressed
Replace the foot controller
jack assy.
• Replace foot controller
or
• Replace the foot controller
jack assy.
Connect the foot controller; when the
foot controller is pressed does the
resistance across pins 1-3 of the foot
controller jack assy. connector vary
from several
Ω to 10k Ω ?
Is the resistance between pins 2-3 on the
foot controller jack assy. connector normal?
• Foot controller not connected ... 1Ω or less
• Foot controller connected ... ∞
N
N
Replace main PCB assy.
Y
Y
