5 - 14
Failure Investigation for Electronic Parts
Cassette LED does not light
Cassette LED does not light
Is the cassette switch assy. resistance
normal?
•
Cassette switch assy. resistance
When switch is pressed ... 1Ω or less
When switch is not pressed ... ∞
N
Replace main PCB assy.
Replace the cassette switch
assy.
Y
