5 - 11
Failure Investigation
for Electronic Parts
Failure Investigation for Electronic Parts
Problems with vertical needle movement and backstitching
Problems with vertical needle movement
and backstitching
Replace SSVR PCB assy.
Replace NP PCB-S assy.
Is the BWSW assy. OFF?
When the upper shaft pulley is turned
slowly by hand, does the voltage
across pins 2-1, pins 4-1 and pins 5-
1 of CN1 (S2) or CN2 (S3) on the
main PCB assy. vary 0-5V DC?
Are the resistance values for the
start/stop switch, backstitching switch,
needle lifter switch normal?
• Switch resistance values
When switch is pressed ... 1Ω or less
When switch is not pressed ... ∞
N
N
N
Adjust the BWSW assy.
assembly
Replace main PCB assy.
Y
Y
Y
S2 : CS8000 Series
S3 : CS8100 Series
