Brother CS8000 Series User Manual

2 - 27
Thread tension mechanism
Main unit
Disassembly
4
Damper holder assy. disassembly
1. Remove the screws 1 (two), and remove the spacers 1 (two) and the oil
damper 2.
2. Remove retaining ring E2, and remove the damper gear shaft, gear A and
gear B.
1 2
1
1
Retaining ring E2
5
Thread hook assy. removal
1. Remove screws 1 (bolt, socket M3X6) (two), and remove the thread hook
assy.
1
