Brother DCP-8157DN User Manual

2-6
Confidential
 A4 model
Fig. 2-3
ADF cover
Document feed
roller ASSY 2
First side CIS unit
First side document hold
First side document scanning position sensor PCB
ADF cover/document detection sensor PCB
Document glass
Document cover
ADF document output support flap
ADF cover actuator
Document pick-up roller
Document detection actuator
ADF separate pad
Document feed
roller ASSY 1
ADF document support
Paper guide
Second side CIS unit
Document ejection roller
Document
separate roller
First side document scanning
position actuator
Second side document hold
Second side document scanning position actuator
Second side document scanning position sensor PCB

Brother DCP-8157DN Specifications

General

Print Technology	Laser
Max Resolution (B&W)	1200 x 1200 dpi
Duplex Printing	Yes
Scan Resolution	1200 x 1200 dpi
Network Ready	Yes
Functions	Copier, Printer, Scanner
Scanner Type	Flatbed, ADF
Interface	USB, Ethernet
Print Resolution	1200 x 1200 dpi
Connectivity	USB, Ethernet
Operating Systems Compatibility	Windows, Mac, Linux
