Brother DCP-8157DN User Manual

3-20
Confidential
8. DISASSEMBLY FLOW CHART
Disassembly / Re-Assembly (second)
9.1 Duplex tray
5/5
9.2 Paper tray 1
5/5
9.9.3 ADF document
output support flap
5/5
9.9.4 Document sub
tray
5/5
9.39 T1 roller holder
ASSY
5/10
9.9.12 Drive frame
ASSY / Document feed
roller ASSY 1
35/50
9.9.13 ADF motor
ASSY
10/10
9.9.2 Hinge R
15/15
9.9.12 Document
ejection shaft
5/5
9.9.12 Document
ejection roller ASSY 1
5/10
9.9.14 First side
document hold
5/5
9.9.12 Lower ADF
chute
15/20
9.9.1 Hinge ASSY L
15/15
9.7 Side cover L /
Access cover
20/20
9.9 Main shield cover
plate
20/25
9.9 ADF unit
70/50
9.9.5 ADF cover ASSY
5/10
9.9.6 Gear cover
10/10
9.9.7 Document
separate roller ASSY
5/10
9.9.10 Document feed
roller ASSY 2
5/10
9.9.10 Upper ADF
chute
15/20
9.9.11 ADF cover/
document detection
sensor PCB ASSY / First
side document scanning
position sensor PCB ASSY
/ Second side document
scanning position sensor
PCB ASSY
30/30
9.9.8 ADF separation
pad spring / ADF
separation pad
Legal model
10/30
A4 model 10/10
9.9.9 Second side CIS
unit / Second side CIS
flat cable (duplex
scanning models only)
10/15
9.11.1 First side CIS
unit
10/30
9.8 Side cover R ASSY
20/20
9.5 MP cover ASSY
5/10
9.5 MP paper guide
ASSY
10/10
9.11.1 Document
scanner top cover
ASSY
20/20
9.16 NCU PCB ASSY
50/60
9.13 Wireless LAN
PCB ASSY
10/20
9.12 Joint cover
90/100
9.14 USB host PCB
ASSY
20/30
9.15 Speaker unit
20/30
9.11 Document
scanner unit
30/40
9.42 MP roller holder
ASSY / MP separation
pad ASSY / MP
separation pad spring
20/40
9.10 Panel cover /
Printed panel cover
5/5
9.10 Control panel
ASSY
15/25
9.10 Panel PCB ASSY
30/30
9.10 Touch panel plate
25/25
9.10 LCD / Touch panel
ASSY
5/5
9.10 Rubber key L
5/15
9.10 Rubber key R
5/5
9.10 Panel light guide
5/5
9.10 Panel cover
5/5
9.10 Control panel
ASSY
20/20
9.10 Panel PCB ASSY
20/20
9.10 Rubber key C
25/25
9.10 Rubber key L
5/25
9.10 Rubber key R
5/10
9.10 Caution lamp lens
/ Panel light guide
5/5
9.10 LCD cover / Back
light ASSY / LCD
15/15
Touch panel models
Non touch panel models

Brother DCP-8157DN Specifications

General

Print Technology	Laser
Max Resolution (B&W)	1200 x 1200 dpi
Duplex Printing	Yes
Scan Resolution	1200 x 1200 dpi
Network Ready	Yes
Functions	Copier, Printer, Scanner
Scanner Type	Flatbed, ADF
Interface	USB, Ethernet
Print Resolution	1200 x 1200 dpi
Connectivity	USB, Ethernet
Operating Systems Compatibility	Windows, Mac, Linux
