Brother HL-L3210CW - Page 143

3-5
Confidential
Paper eject ASSY Taptite bind B M4x12 1
(Side)
0.8±0.1 (8±1)
2
(Top)
1.1±0.1 (11±1)
DX drive cover Taptite bind B M4x12 1 0.8±0.1 (8±1)
Duplex tray Taptite bind B M4x12 2 0.8±0.1 (8±1)
Wire cover Taptite bind B M4x12 1 0.75±0.05 (7.5±0.5)
Cover plate Taptite pan (washer) B
M4x12DA
1 0.75±0.05 (7.5±0.5)
Taptite cup S M3x8 SR 1 0.75±0.05 (7.5±0.5)
Taptite bind B M4x12 2 0.75±0.05 (7.5±0.5)
LVPS ground wire Screw pan M4x8 1 0.5±0.1 (5±1)
LVPS plate lower ASSY Taptite pan (washer) B
M4x12DA
4 0.75±0.05 (7.5±0.5)
Taptite cup S M3x8 SR 2 0.5±0.05 (5±0.5)
Low-voltage power supply
PCB
Taptite cup S M3x6 SR 3 0.6±0.05 (6±0.5)
Registration mark sensor
ASSY
Taptite bind S M3x5 1 0.5±0.1 (5±1)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
