CHAPTER 4 ADJUSTMENTS AND
UPDATING OF SETTINGS,
REQUIRED AFTER PARTS
REPLACEMENT
1. IF YOU REPLACE THE MAIN PCB
■ What to do after replacement
• Configure for Country/Region and Model (Function code 74)
• Installing the Firmware (Sub Firmware and Main Firmware)
• Initializing the EEPROM of the Main PCB (Function code 01)
• Adjusting Touch Panel (Function code 61) (Touch panel models only)
• Continuous Adjustments of Density and Registration Sensor (Function code 73)
• Setting the Serial Number (Function code 80)
■ What you need to prepare
(1) One USB cable
(2) Create a temporary folder on the C drive of the computer (Windows
®
XP or later).
(3) Service setting tool (SvSettingTool)
(Only when setting the Serial Number using computer.)
Copy it into the temporary folder that has been created in the C drive.
(4) Download utility (Filedg32.exe)
Copy it into the temporary folder that has been created in the C drive.
(5) Maintenance printer driver (Maintenance_driver.zip)
When the maintenance printer driver is not installed, copy this file into the temporary
folder created on the C drive, and extract the copied file. Refer to “APPENDIX 3
INSTALLING THE MAINTENANCE PRINTER DRIVER” to install the driver.
(6) Firmware
(7) Touch pen
(8) Memory access tool (MemoryAccessTool.exe) (only for using SvSettingTool.)
Sub firmware djf file (ex. ******_A.djf)
Main firmware djf file (ex. ******_A.djf)
To Next Page
