Brother HL-L3210CW - Disassembly Flow

3-17
Confidential
8. DISASSEMBLY FLOW
9.2 T1 separation
pad ASSY
H: 2 / S: 0
9.3 Back cover
H: 0 / S: 0
9.6 Side cover L
H: 10 / S: 2
9.8 Back cover lower
H: 3 / S: 0
9.15 WLAN PCB
H: 4 / S: 0
9.9 Top cover ASSY
H: 9 / S: 15
9.13 High-voltage
power supply PCB
H: 11 / S: 5
9.10 LCD panel
ASSY
H: 22 / S: 7
9.7 Side cover R
H: 10 / S: 2
9.4 Rear flapper sub
ASSY
H: 0 / S: 0
9.5 Fuser cover
ASSY / Fuser unit
H: 0 / S: 4
9.20 Eject sensor
PCB
H: 1 / S: 0
9.27 Registration
mark sensor L PCB /
Registration mark
sensor R PCB
H: 1 / S: 1
9.12 LED ASSY
(Y/M/C/K) / LED
ASSY flat cable
(Y/M/C/K)
H: 7 / S: 0
9.24 Paper eject
ASSY
H: 0 / S: 3
9.13 Develop release
sensor PCB
H: 1 / S: 0
9.14 Fan
H: 2 / S: 0
9.17 Cartridge sensor
relay flat cable
H: 1 / S: 1
9.18 Develop release
clutch
H: 5 / S: 1
9.18 Process drive
unit
H: 1 / S: 10
9.19 Paper feed drive
unit
H: 3 / S: 5
9.21 Manual feed
cover ASSY
H: 2 / S: 0
9.23 Paper feed unit
H: 2 / S: 4
9.22 Roller holder
ASSY
H: 0 / S: 0
9.25 Duplex tray
H: 0 / S: 3
9.26 Low-voltage
power supply PCB
H: 0 / S: 15
9.16 Main PCB
H: 0 / S: 3
9.19 T1 pick-up
clutch / Registration
clutch
H: 2 / S: 0
9.11 LED control
flat cable / LED
control PCB
H: 0 / S: 5
Hook (H) / Screw (S) (pcs)
