(6) Remove the five Taptite bind B M4x12 screws to remove the Paper feed drive unit.
(7) Release the hook to remove the External temperature/humidity sensor PCB from the
Paper feed drive unit.
Fig. 3-61
Paper feed drive unit
Taptite bind B
M4x12
Taptite bind B M4x12
Taptite bind B M4x12
Hook
External temperature/
humidity sensor PCB
