5-47
Confidential
1.3.22 Configure for country/region and model (Function code 74)
< Function >
This function is used to customize the machine according to language, function settings, and
worker switch settings.
< Operating Procedure >
For models with touch panel
(1) Press the [7], and then the [4] in the initial state of maintenance mode. The spec code
currently set is displayed on the LCD.
(2) Enter the spec code (four digits) you want to set.
(3) Press the [Mono Start] to save the new setting, and “PARAMETER INIT” is displayed on
the LCD. The machine then returns to the initial state of maintenance mode.
For models without touch panel
(1) Press the [▲] or [▼] in the initial state of maintenance mode to display “MAINTENANCE
74” on the LCD, and press the [OK]. The spec code currently set is displayed on the LCD.
(2) Enter the first two digits of the spec code. Press the [▲] or [▼] to select the first digit, and
press the [OK]. The cursor moves to the second digit. Press the [▲] or [▼] to select the
second digit, and press the [OK]. The cursor moves to the fourth digit.
(3) Press the [▲] or [▼] to select the third digit and the fourth digit (skip the invalid number
selected), and press the [OK].
(4) Press the [Go] to save the new setting, and “PARAMETER INIT” is displayed on the LCD.
The machine then returns to the initial state of maintenance mode.
■ Setting by spec code list
MODEL Country Code Country Code (Detail)
HL-3160CDW China 0320 --- ---
HL-3190CDW China 0020 --- ---
HL-L3210CW Brazil 0042 --- ---
Canada 0001 --- ---
CEE-General 0003 --- ---
France/Belgium/Netherlands 0003 --- ---
Germany 0003 --- ---
Gulf 0041 --- ---
Italy/Iberia 0003 --- ---
Korea 0044 --- ---
New Zealand 0027 --- ---
Pan-Nordic 0003 --- ---
Switzerland 0003 --- ---
U.S.A 0001 --- ---
UK 0003 --- ---
HL-L3230CDN
Argentina 0136 --- ---
Singapore 0140 --- ---
