Brother HL-L3210CW Service Manual

5-53
Confidential
DX_CO:00000000 Total number of two-sided color pages printed
DX_MO:00000000 Total number of two-sided monochrome pages printed
TTLPCPT:00000000 Total number of pages printed via PC
DX_PCPT:00000000 Total number of two-sided pages printed via PC
CL_PCPT:00000000 Total number of color pages printed via PC
MN_PCPT:00000000 Total number of monochrome pages printed via PC
DX_CPCP:00000000 Total number of two-sided color pages printed via PC
DX_MPCP:00000000 Total number of two-sided monochrome pages printed via PC
TTL_OTH:00000000 Total number of pages printed by other methods
DX_OTH:00000000 Total number of two-sided pages printed by other methods
CL_OTH:00000000 Total number of color pages printed by other methods
MN_OTH:00000000 Total number of monochrome pages printed by other methods
DX_COTH:00000000 Total number of two-sided color pages printed by other methods
DX_MOTH:00000000
Total number of two-sided monochrome pages printed by other methods
CCVRGUSI:4.32%* Average coverage by the current cyan toner cartridge
CCVRGACC:3.47% Accumulated average coverage of cyan toner cartridge
MCVRGUSI:4.32%* Average coverage by the current magenta toner cartridge
MCVRGACC:3.47% Accumulated average coverage of magenta toner cartridge
YCVRGUSI:4.32%* Average coverage by the current yellow toner cartridge
YCVRGACC:3.47% Accumulated average coverage of yellow toner cartridge
KCVRGUSI:4.32%* Average coverage by the current black toner cartridge
KCVRGACC:3.47% Accumulated average coverage of black toner cartridge
CDRUM:00000000 Number of cyan drum rotations
MDRUM:00000000 Number of magenta drum rotations
YDRUM:00000000 Number of yellow drum rotations
KDRUM:00000000 Number of black drum rotations
CTN_RND: 00000000 Number of cyan develop roller rotations
MTN_RND: 00000000 Number of magenta develop roller rotations
YTN_RND: 00000000 Number of yellow develop roller rotations
KTN_RND: 00000000 Number of black develop roller rotations
MP_PG:00000000 Paper input for MP tray (Display only for MP models)
MN_PG:00000000
Paper input for manual feed (Display only for manual feed slot models)
TR1_PG:00000000 Paper input for T1
DX_PG:00000000 Paper passed through duplex tray
A4+LTR:00000000 Total paper input for A4 and Letter
LG+FOL:00000000 Total paper input for Legal and Folio
B5+EXE:00000000 Total paper input for B5 and Executive
ENVLOP:00000000 Paper input for Envelope
A5 :00000000 Paper input for A5 (including A5 Landscape)
OTHER :00000000 Paper input for other sizes
PLTNRE:00000000 Total printed pages of plain, thin, and recycled paper
TKTRBD:00000000 Total printed pages of thick, thicker, and bond paper
ENVTYP:00000000 Total printed pages of envelope, thick envelope, and thin envelope
COLOR:00000000 Full-color printed pages
LTHD:00000000 Printed pages on letter head
LABEL:00000000 Printed pages on label
HAGAKI:00000000 Printed pages on postcard
LCD Description

Brother HL-L3210CW Specifications

General

N-up printing	2, 4, 9, 16, 25
Duplex printing	No
Print technology	LED
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Duplex print speed (black, normal quality, A4/US Letter)	6 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PDF, PostScript 3, XPS
Display	LCD
Product color	Gray
Market positioning	Home & office
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Kindle Fire Printing, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, Web Services (Print/Scan)
Paper input type	Cassette, Sheetfed
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Sustainability certificates	Blue Angel, ENERGY STAR
Maximum internal memory	- MB
Sound pressure level (printing)	45 dB
Envelopes sizes	C5, Com-10, DL, Monarch
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Package depth	589 mm
Package width	513 mm
Package height	372 mm
Package weight	20700 g
Power consumption (off)	0.04 W
Power consumption (standby)	8.8 W
Power consumption (printing)	390 W
Power consumption (PowerSave)	1 W
Energy Star Typical Electricity Consumption (TEC)	0.9 kWh/week
Standard interfaces	USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	AC
Bundled software	Nuance PaperPort 14 SE
Included black & color (CMYK) cartridges capacity	1000 pages
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	461 mm
Width	410 mm
Height	252 mm
