2-63
Confidential
■ Electrodes location of main body
Fig. 2-6
■ Electrodes location of the drum unit
Fig. 2-7
Belt transfer roller
Grid
Charging (Corona wire)
Drum cleaner
Waste toner sensor
Waste toner box common
Waste toner box cleaning roller
Belt
common
