2-76
Confidential
■ Error code 9901
An error occurred with the value measured during manual color registration performed from
the control panel.
<User Check>
• Check if the toner cartridges are set in the correct order of colors.
• Replace the toner cartridge.
• Replace the drum unit.
• If the belt unit has a scratch, replace it.
• If “WT Box End Soon” is displayed on the LCD and the belt unit has dirt, replace the waste
toner box.
■ Error code 9902
Dot counter or develop roller counter of color toner has reached the upper limit during auto
color registration performed from the control panel.
<User Check>
• Replace the corresponding toner cartridge.
Step Cause Remedy
1
Dirt on the registration mark
sensor L / registration mark
sensor R
Clean the registration mark sensor L /
registration mark sensor R.
2
Connection failure of the
registration mark sensor L /
registration mark sensor R
harness
Reconnect the registration mark sensor L /
registration mark sensor R harness.
3
Failure in printed measurement If failure occurs when printing “K/W/Y/M/
C” in “Function code 71”, refer to “4.3
Troubleshooting for Image Defects” in this
chapter and take a measure.
4
Registration mark sensor L or
registration mark sensor R failure
Replace the registration mark sensor
ASSY.
5 Main PCB failure Replace the main PCB.
Step Cause Remedy
1 Main PCB failure Replace the main PCB.
To Next Page
