Setting Up the P-touch
5
1
Inserting a Tube 1
a Press the cover open button to open the top cover.
b Pull the tube release lever up.
c Pass the tube as shown in the illustration so that the end of the tube reaches the “ ” mark on the
P-touch, and then push the tube release lever down.
d Close the top cover.
• Do not use tube which is dirty, bent, flattened, has a rough surface or uneven tube thickness, or is defective
in any other way.
• When using the P-touch, position it so direct sunlight does not enter the P-touch through the tube exit slot.
• You can use the tube half-cut adjuster to adjust the depth of half cuts to one of three settings.
• If the tube is jammed or not cut completely, use the (Feed and Cut) button to manually cut the tube
completely. Press and hold the button for 2 to 10 seconds until the (Power) indicator changes from
being lit in green to flashing in green, and then release it. The tube will be cut when the button is released.
