Technical Manual Version 001 BRUKER BIOSPIN 15 (55)
4
Product Status and
Modifications 4
Introductory Status 4.1
Program File
The name of the program file includes the layout number and the EC level.
Configuration and Settings 4.2
Jumper Setting
There are no jumpers on this board. Some configuration settings have been made
using zero Ohm resistors and should not be changed.
PCI Bus
The following four resistors define the interrupt wiring.
Part
Number
Name
Layout
Number
Modification
Program
File
Firmware
Jumper
Setting
H12513F1 DPP1 H4P2820b Yes No No
Table 4.1. PCI Interrupt Selection
Signal Mounted Resistor Comment
INT_A Yes R99 Interrupt to PCI on pin „A“
INT_B No R100 Not connected.
INT_C No RB30 Not connected.
INT_D No RB29 Not connected.
