Technical Manual Version 001 BRUKER BIOSPIN 17 (55)

Description 5

Versions 5.1

Structure 5.2

Figure 5.1: DPP1 Block Diagram

Name Part Number EC Number

Firmware

Number

Increments

DPP H12513 No 28 Bit LVDS (test version)

DPP1 H12513F1 01 No 48 Bit LVDS

DPP1 H12513F1 02 No Removing NV configuration
